Description

ELECTRICAL SPECIFICATIONS: Frequency Range 380 - 400 MHz. Gain 13 dBi. (11 dBd.) Bandwidth Entire Band Polarization Vertical or Horizontal Input Impedance 50 Ohms. Radiation Pattern Directional Horizontal Beam-width –Half Power Points. 50 Degrees Vertical Beam-width –Half Power Points. 40 Degrees Front to Back Ratio 16 dB. VSWR – Better Than 1:1.5 RF Power Handling Capacity 250 Watts. Input Termination N-Female
