Description

Technical Specifications Model No 300 300 72 . Frequency 890 - 960 MHz 1710 - 1880 MHz 1600 - 2170 MHz . Insertion loss . 890 - 960 MHz (Low Band) 0.2 dB 1710-1880 MHz (Mid Band) 0.2 dB 1920-2170 MHz(High Band) 0.3 dB Input power 890 - 960 MHz (Low Band) <= 250 Watts 1710-1880 MHz (Mid Band) <= 250 Watts 1920-2170 MHz(High Band) <= 250 Watts IMP 2x43dBm carrier at either input 160 dBc min Rejection > 65 dB . Isolation between bands > 50 dB . Return Loss > 20 dB VSWR <1.2:1 Impedance 50 +/- 1 Ohms Connector type 7/16 DIN female Application Indoor / Outdoor Temperature -20ºC to +70 ⁰C Humidity 95% Protection IP 65
