Description

Electrical Specification Characteristic Impedance 50 ohm Frequency Range DC- 3 GHz VSWR <1.2 Contact Resistance Inner Conductor : < 1.5 m Ω Outer Conductor : < 1.0 m Ω Dielectric withstanding Voltage >2500V RMS, 50Hz, At sea Level Dielectric Resistance > 5000 M Ω RoHS Compliance Mechanical Durability Mating cycle ≥500 _____________________________________________________________________________________________ Material Specification Material Plating Body Brass White Bronze Insulator Teflon/PTFE Center Conductor Phosphor Copper Gold(AU)
