A Low PIM 100 Watt N male dummy termination load is a robust RF component designed to terminate unused 50-ohm ports in high-power, multi-carrier systems like DAS, BTS, and LTE/5G networks. It ensures minimal signal reflection and suppresses passive intermodulation (PIM), which is essential for maintaining signal clarity in dense RF environments. 🔧 Key Specifications (based on real-world models like SRFS Teleinfra and Maniron): • Power Rating: 100 watts average, with peak handling up to 2.5 kW (short bursts) • Frequency Range: DC to 3 GHz (some models up to 4 GHz) • Impedance: 50 ohms • VSWR: ≤ 1.20:1 for excellent impedance matching • PIM Performance: As low as ≤ -155 dBc @ 2×43 dBm • Connector: N male (threaded, rugged, and weather-resistant) • Construction: • Body: Aluminum or nickel-plated brass • Contact: Gold- or silver-plated phosphor bronze or BeCu • Insulator: PTFE • Dimensions: ~120 × 100 × 60 mm • Weight: ~650 g • Operating Temp: -55°C to +85°C 🛠️ Applications: • Terminating high-power RF ports in telecom infrastructure • RF test benches and calibration setups • Outdoor and indoor deployments requiring low PIM and high durability
